Description
Special Features
DVGW approved
Up to size 11/4″ approved for low noise, Group 1 without limitations
The outlet pressure is set by turning the adjustment knob
The set pressure is directly indicated on the set point scale
The adjustment spring is not in contact with the potable water
The valve insert is of high quality synthetic material and can be fully exchanged
Integral fine filter
Also available without fittings
Easily retrofittable to convert valve to a reverse-rinsing filter combination
Can be retrofitted with an inlet non-return valve
Inlet pressure balancing – fluctuating inlet pressure does not influence outlet pressure
Light weight
| Technical Data | |
|---|---|
| Operating temperature | Maximum 40 °C with clear filter bowl Maximum 70 °C with brass filter bowl |
| Minimum pressure drop | 1.0 bar |
| Connection size | 1/2″ bis 2″ |
