Description
Features
Working Pressure
25 Bar
Working Temperature
-10 C to 100 C
Coating
- 1/2″ to 3/4″ threaded to BS 2779 (ISO7)
- 1″ to 2″ threaded to BS 10266 (ISO7)
- Also available threaded to ANSI B 1.20.1
Material
| No. | Parts | Materials | Specification |
|---|---|---|---|
| 1 | Body | Brass | EN12165 CW617N |
| 2 | Bonnet | Brass | EN12165 CW617N |
| 3 | Stem | Brass | EN12165 CW617N |
| 4 | O-Ring | EPDM | – |
| 5 | Locating Pin | Stainless Steel 304 | – |
| 6 | Directed Circle | PC+ABS | – |
| 7 | Test Valve Body | Brass | EN 12165 CW617N |
| 8 | Seal Ring | EPDM | – |
| 9 | Set Screw | Brass | – |
| 10 | Handwheel | PC+ABS | – |
